| Brand Name: | GPE |
| Model Number: | LP803132 |
| MOQ: | 3000 |
Li Polymer Battery is an advanced rechargeable battery featuring lithium-based chemistry in a polymer electrolyte. It delivers superior performance with overdischarge protection at 2.75V, charging voltage up to 4.2V, charging current of 1C, and a wide discharging temperature range of -20 to 60℃. Known for its lightweight, flexible design, this battery is ideal for portable devices including smartphones, tablets, and laptops.
| Property | Value |
|---|---|
| Short Circuit Protection | Yes |
| Discharging Temperature | -20-60℃ |
| Discharging Current | 2C |
| Overcharge Protection Function | Yes |
| Type | Li Polymer Battery |
| Overcharge Protection Voltage | 4.25V |
| Charging Voltage | 4.2V |
| Capacity | 1300mAh |
| Charging Current | 1C |
| Voltage | 3.7V |
| NO. | Items | Specifications |
|---|---|---|
| 1 | Mode | 802132 |
| 2 | Size | 8*31*32mm |
| 3 | Charge voltage | 4.2V |
| 4 | Nominal voltage | 3.7V |
| 5 | Nominal capacity | 700mAh @ 0.2C Discharge |
| 6 | Charge current | Standard Charging: 0.2C Rapid charge: 1.0C |
| 7 | Standard Charging method | 0.2C CC charge to 4.2V, then CV charge till charge current decline to ≤0.05C |
| 8 | Charging time | Standard Charging: 3.0 hours (Ref.) Rapid charge: 2 hours (Ref.) |
| 9 | Max. charge current | 1.0C |
| 10 | Max. discharge current | 1.0C |
| 11 | Discharge cut-off voltage | 3.0V |
| 12 | Operating temperature | Charging: 0℃~45℃ Discharging: -20℃~60℃ |
| 13 | Storage temperature | -10℃~ +45℃ |
| 14 | PACK Weight | Approx: 16g |
The GPE Li Polymer Battery provides reliable power with short circuit protection, 2C discharging current, and 1C charging current. With overdischarge protection at 2.75V, it's ideal for long-lasting power requirements.
GPE's Li Polymer Battery is available as a Lithium Polymer Pack, Li Polymer Battery Pack, and Lithium Polymer Pack with 2C Discharging Current and 3000mAh Capacity. Designed with Overdischarge Protection Voltage of 2.75V and Short Circuit Protection for safety.
We provide comprehensive technical support and services for Li Polymer Battery products. Our knowledgeable team is available to assist with:
Li Polymer Batteries are securely packaged using appropriate protective materials including padded bags, cardboard boxes, or bubble wrap. All packages are clearly labeled with necessary shipping information including return address, receiver's address, and content description.
We use reliable carriers and provide tracking numbers for all shipments. Packages are insured to cover potential damages during transit, ensuring safe delivery to your destination.
