Lithium Polymer Battery Pack

3.7V 43Ah Lithium Polymer Battery with 500times Cycle Life for Beauty Devices

All Category

Solar Energy Storage Batteries

Rechargeable Lithium Batteries

Portable Power Station

Mrs. Linda

linda@szgpebattery.com

+86 15817210994

Contact Now

3.7V 43Ah Lithium Polymer Battery with 500times Cycle Life for Beauty Devices

Model Number:	503048
MOQ:	2000pieces
Packaging Details:	Bulk packing
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UN38.3, MSDS, IEC62133, RoHS

Voltage:

Weight:

645±30g

Capacity:

Cycle Life:

500times

Charge Voltage:

4.30V

Discharge Voltage:

2.75V

Supply Ability:

50'000Pieces daily

Highlight:

60ah Power Polymer Li Ion Battery

503048 3.7V Polymer Li Ion Battery

43ah Li Ion Power Polymer Battery

Product Description

503048 3.7V Polymer Li Ion Battery 3.7V 43Ah 50Ah 60Ah High Capacity Power Polymer

Product Overview

3.7V 43Ah / 50Ah / 60Ah 503048 Lithium Polymer Battery Pack with 500 Cycle Life

KC 3.7V 43Ah Lithium Polymer 803035 Li-Polymer 50Ah / 60Ah 3.7V LiPo Battery

Technical Specifications

NO.	Item	Specifications
1	Minimum capacity	43Ah \| 0.33C@4.30~2.75V@25±2℃
2	Typical capacity	45Ah \| 0.33C@4.30~2.75V@25±2℃
3	ACIR@1KHz	≤1.0mΩ \| 58%SOC@25±2℃
4	Weight	645±30g
5	Charge cut-off voltage	4.30V
6	Discharge cut-off voltage	2.75V
7	Nominal voltage	3.7V \| 0.33C@4.30~2.75V@25±2℃
8	Operating temperature	Charge: 0~5℃ \| 0.05C(max) to 4.20V 6~15℃ \| 0.2C(max) to 4.20V 16~24℃ \| 0.5C(max) to 4.30V 25~45℃ \| 1.0C(max) to 4.30V 46~50℃ \| 0.5C(max) to 4.20V or 0.2C to 4.25V Discharge: -20~60℃
9	Standard charge method	0.33C CC to 4.30V, 4.30V CV to 0.05C
10	Standard discharge method	0.5C
11	Max charge current	1.0C
12	Max discharge current	3.0C
13	Storage temperature (58%SOC state)	12month \| -10~25℃@80%RH max 3month \| -10~35℃@80%RH max 1month \| -10~45℃@80%RH max

Product Performance Description

Battery thickness 7.00mm, length 295mm, width 147mm, weight 645g, capacity 43Ah. Single piece of the main material is lithium iron phosphate, the process is soft pack laminated type, featuring high energy density and high rate. The shell is made of aluminum plastic film material, making the overall weight light.

Lithium Polymer battery pack 3.7V 43Ah 503048 li-polymer Rechargeable li-pol battery

Test Procedure and Standards

Item	Test method	Standard
1	Appearance	Visual
2	Dimension	Caliper for dimension
3	Weight	Balance
4	Shipment voltage	Voltmeter
5	Initial Internal Impedance	Measure the AC impedance at 1kHz
7	Cycle Life (25±2℃, With splint, Rest for 30 min between each cycle)	Charge: 0.33C CC charge to 4.30V, 4.30V CV charge to 0.05C cut-off; Discharge: 1.0C CC discharge to 2.75V
9	Leakage Test	The battery which is fully charged shall be stored at 60±2℃ and 85±5% RH for 7 days
10	H/L Temp. Characteristic (Hold for 2h@55℃ or 4h@-20℃ after full charging)	Charge: 0.5C CC charge to 4.30V, 4.30V CV charge to 0.05C cut-off at 25±2℃ Discharge: 1.0C CC discharge to 2.5V at -20±2℃; 1.0C CC discharge to 2.75V at 55±2℃

Standard Packaging

Standard packaging for 3.7V 7.4V lithium ion polymer battery pack

Why Choose Us

Technology

All-weather applicability (-30~60℃)
Highly safe battery design technology with the newest electrolyte and separator technology applied
Full Coverage of Battery Variety: Lithium ion Cylindrical battery, lithium polymer battery, LiFePO4 battery, Solar Energy Storage battery pack, square aluminum shell, Primary Battery, etc.

R&D

Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.

Quality Control

Certificates

CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.

Factory Tour

Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China.

We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery pack since 2001.
