| Model Number: | LP802535 |
| MOQ: | 3000pieces |
| Packaging Details: | Bulk packing |
| Payment Terms: | T/T |
We provide more than 1000 models of 3.7V LiPo batteries, with thickness ranging from 1mm-11mm and capacity from 20mAh-10,000mAh.
We offer customized 3.7V, 7.4V, 11.1V, and 14.8V lithium polymer battery services with any capacity and size requirements.
Our 3.7V LiPo batteries come equipped with PCM and wires, and we can add JST/Molex/Hirose connectors free of charge.
| Polymer Battery 3.7V | Brand Name | GPE |
| Place Origin | Guangdong, China | |
| Nominal Voltage | 3.7V | |
| Initial Voltage | ≥3.8V | |
| Initial Capacity | Real Capacity | |
| Material | Lithium Cobaltate/Ternary Lithium | |
| Basic Specification | Charging Voltage | 4.2V |
| Discharge Cut-Off Voltage | 2.45V~3V | |
| Max Charge Current | 1C | |
| Max Discharge Current | 1C | |
| Operating Temperature | Charge: 0°C to 45°C Discharge: -20°C to 60°C |
|
| Storage Temperature | -20°C to 45°C | |
| Wire & Pin | Can be customized | |
| PCBA/Connector | Can be customized | |
| Customize Service | Can be customized | |
| OEM/ODM | Available | |
| Warranty | 12 Months | |
Shenzhen Gold Power Energy offers over 1000 models of lithium polymer batteries with capacity ranging from 20mAh to 5000mAh to meet various application requirements.
| Model | Dimension | With PCM Dimension | Capacity |
|---|---|---|---|
| 302025 | 3.0*20*25mm | 3.2*21*27.5mm | 3.7V 100mAh |
| 302530 | 3.0*25*30mm | 3.2*26*32.5mm | 3.7V 180mAh |
| 401824 | 4.0*18*24mm | 4.2*19*26.5mm | 3.7V 180mAh |
| 402525 | 4.0*25*25mm | 4.2*26*27.5mm | 3.7V 200mAh |
| 483450 | 4.8*34*50mm | 5.0*35*52.5mm | 3.7V 850mAh |
| 502030 | 5.0*20*30mm | 5.2*21*32.5mm | 3.7V 240mAh |
| 502525 | 5.0*25*25mm | 5.2*26*27.5mm | 3.7V 180mAh |
| 503030 | 5.0*30*30mm | 5.2*31*32.5mm | 3.7V 430mAh |
| 523450 | 5.2*34*50mm | 5.4*35*52.5mm | 3.7V 1000mAh |
| 553444 | 5.5*34*44mm | 5.7*35*46.5mm | 3.7V 850mAh |
| 553640 | 5.5*36*40mm | 5.7*37*42.5mm | 3.7V 850mAh |
| 553759 | 5.5*37*59mm | 5.7*38*61.5mm | 3.7V 1400mAh |
| 602030 | 6.0*20*30mm | 6.2*21*32.5mm | 3.7V 300mAh |
| 602240 | 6.0*22*40mm | 6.2*23*42.5mm | 3.7V 500mAh |
| 602535 | 6.0*25*35mm | 6.2*26*37.5mm | 3.7V 500mAh |
| 602663 | 6.0*26*63mm | 6.2*27*65.5mm | 3.7V 1000mAh |
| 603030 | 6.0*30*30mm | 6.2*31*32.5mm | 3.7V 520mAh |
| 603040 | 6.0*30*40mm | 6.2*31*42.5mm | 3.7V 750mAh |
| 603048 | 6.0*30*48mm | 6.2*31*50.5mm | 3.7V 900mAh |
| 603450 | 6.0*34*50mm | 6.2*35*52.5mm | 3.7V 1050mAh |
| 702040 | 7.0*21*40mm | 7.2*22*42.5mm | 3.7V 500mAh |
| 753048 | 7.5*30*48mm | 7.7*31*50.5mm | 3.7V 1200mAh |
| 803035 | 8.0*30*35mm | 8.2*31*37.5mm | 3.7V 800mAh |
Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.
CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.
Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have been providing various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery packs since 2001.
