Lithium Polymer Battery Pack
>
7.4V 2000mAh Lipo Battery with 500 Times Cycle Life Lithium Polymer Rechargeable Battery

7.4V 2000mAh Lipo Battery with 500 Times Cycle Life Lithium Polymer Rechargeable Battery

Model Number: 654060-2S654060
MOQ: 3000pieces
Packaging Details: Bulk packing
Payment Terms: T/T
Detail Information
Place of Origin:
China
Certification:
CE,ROHS, MSDS,CB,CE, KC
Voltage:
7.4V
Capacity:
2000mAh
Cycle Life:
500times
Dimensions:
6.5*40*60mm
Weight:
85g
Max Discharge Current:
Constant Current 1C End Voltage FD
Supply Ability:
100'000Pieces daily
Highlight:

CB Lipo Battery Pack

,

2000mAh Lipo Battery Pack

,

3000mAh Lipo Battery

Product Description
2S 3S 4S Lipo Battery 2000mAh 3000mAh, KC Lipo Battery Pack 11.1V 7.4V

KC Lipo Battery Pack 11.1V 7.4V 2S 3S 4S Lipo Battery 2000mAh Battery Lipo 3000mAh

Technical Specifications
Item Specifications
Min capacity 3500 mAh 0.2C Discharge
Initial Impedance ≤110mΩ
Weight Approx: 178.5g
Nominal voltage / Fully charge voltage (FC) / Fully discharge voltage (FD) 11.1 V / 12.6 V / 8.40 V
Standard charge current 0.5 C
Standard charging method 0.5C CC charge to FC, then CV charge till charge current decline to ≤0.01C
Charging time Standard Charging Approx 3 hours
Max. charge current Constant Current 1C Constant Voltage FC 0.01 C cut-off
Max. discharge current Constant current 1C end voltage FD
Standard Discharge Current Constant current 0.2 C end voltage FD
Storage temperature -20℃~60℃ (≤1 month), -20℃~45℃ (≤3 month), -20℃~28℃ (≤1 year)
Recoverable capacity No less than 80% of initial capacities
Storage Humidity ≤75% RH
Appearance Without distortion and leakage
Standard testing condition Temperature: 23±5℃, Humidity: ≤75%RH, Atmospheric Pressure: 86-106 Kpa
Product Images

Detailed images for li polymer battery 654060-2S 7.4V 2000mAh lithium rechargeable battery pack

7.4V 2000mAh lithium rechargeable battery pack front view 7.4V 2000mAh lithium rechargeable battery pack side view 7.4V lithium polymer battery pack technical details
Standard Packaging
Standard packaging for 7.4V lithium polymer battery pack
Why Choose Us
Research & Development

Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.

R&D team and equipment for battery development
Certifications

CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.

Battery certifications and quality standards
Factory Tour

Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery pack since 2001.

Factory facilities and manufacturing process
