| Model Number: | ICR18650 |
| MOQ: | 500pieces |
| Packaging Details: | Bulk packing |
| Payment Terms: | T/T |
| Item | Specifications |
|---|---|
| Nominal capacity | 2200mAh 0.2C Discharge |
| Minimum capacity | 2200mAh 0.2C Discharge |
| Nominal voltage | 3.7V |
| Charge current | Standard Charge: 0.2C |
| Charging time | Standard Charging Approx 6 hours |
| Maximum charge current | 2200mA |
| Maximum discharge current | 2200mA |
| Discharge cut-off voltage | 3.0V |
| Charge cut-off voltage | 4.23V |
| Initial impedance | ≤100mΩ |
| Weight | Approx: 50g |
| Operating temperature | Charging: 0℃~45℃, Discharging: -20℃~60℃ |
| Storage temperature | -5℃~35℃ |
| Storage humidity | ≤75% RH |
| Appearance | Without scratch, distortion, contamination and leakage |
| Model No. | Nominal Voltage | Typical Capacity | Size | Charge Rate | Discharging Rate | Weight(g) |
|---|---|---|---|---|---|---|
| ICR14500 | 3.7V | 600mAh | 13.9×48.5±0.3 | 0.2-1C | 0.2-2C | 19.5 |
| ICR14500 | 3.7V | 750mAh | 13.9×48.5±0.3 | 0.2-1C | 0.2-2C | 20 |
| ICR14500 | 3.7V | 800mAh | 13.9×48.5±0.3 | 0.2-1C | 0.2-2C | 20.5 |
| ICR18500 | 3.7V | 1300mAh | 18.0×49.7±0.2 | 0.2-1C | 0.2-2C | 32 |
| ICR18500J | 3.7V | 1400mAh | 18.0×49.7±0.2 | 0.2-1C | 0.2-2C | 31 |
| ICR18500 | 3.7V | 1600mAh | 18.0×49.7±0.2 | 0.2-1C | 0.2-2C | 32 |
| ICR18650 | 3.7V | 2200mAh | 18.0×65.2±0.2 | 0.2-1C | 0.2-2C | 40 |
| ICR18650 | 3.7V | 2600mAh | 18.0×65.2±0.2 | 0.2-1C | 0.2-2C | 45 |
| ICR18650 | 3.7V | 3000mAh | 18.0×65.2±0.2 | 0.2-1C | 0.2-2C | 48 |
| ICR18650 | 3.7V | 3400mAh | 18.0×65.2±0.2 | 0.2-1C | 0.2-2C | 50 |
| ICR26650 | 3.7V | 4500mAh | 26.3×65.0±0.5 | 0.2-1C | 0.2-2C | 80 |
| ICR26650 | 3.7V | 5000mAh | 26.3×65.0±0.5 | 0.2-1C | 0.2-2C | 85 |
| ICR18650P | 3.7V | 2600mAh | 18.0×65.2±0.2 | 0.2-1C | 5C | 45 |
Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.
CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certified.
Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have been providing various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery packs since 2001.
|
