LiFePO4 Battery Cell

3.2V 3400mAh 26650 LiFePO4 Battery Cell with 2000 Cycle Life for Industrial Applications

All Category

Solar Energy Storage Batteries

Rechargeable Lithium Batteries

Portable Power Station

Mrs. Linda

linda@szgpebattery.com

+86 15817210994

Contact Now

3.2V 3400mAh 26650 LiFePO4 Battery Cell with 2000 Cycle Life for Industrial Applications

Model Number:	IFR26650
MOQ:	500pieces
Packaging Details:	Bulk packing
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UN38.3, MSDS, IEC62133, RoHS

Nominal Voltage:

Nominal Capacity:

3400mAh

Cell Weight:

Dimensions:

26*65mm

Max Charge Current:

1C (3300mA)

Max Discharge Current:

2C (6600mA)

Supply Ability:

40'000Pieces daily

Highlight:

lifepo4 lithium iron phosphate battery

26650 lithium iron phosphate battery cell

3.2V 3300mAh LiFePO4 Battery Cell

Product Description

Cylindrical Lithium Iron Phosphate 26650 3.2V 3300mAh LiFePO4 Battery Cell

Lithium Iron Phosphate 26650 3.2V 3300mAh Cylindrical LiFePO4 battery cell

Specifications

Parameter	Value
Size	26*65mm
Charge Voltage	3.65V
Nominal Voltage	3.2V
Nominal Capacity	3400mAh
Cell Weight	Approx. 87g
Charge Current	Standard: 0.5C 1700mA Rapid: 1.0C 3400mA
Standard Charging Method	0.5C CC charge to 3.65V, then CV (3.65V) charge until current ≤0.05C
Charging Time	Standard: 3.0 hours (Ref.) Rapid: 2 hours (Ref.)
Max. Charge Current	1C (3300mA)
Max. Discharge Current	2C (6600mA)
Discharge Cut-off Voltage	2.5V
Cycle Life	>1000 cycles
Operating Temperature	Charging: 0℃~45℃ Discharging: -20℃~60℃
Storage Temperature	-10℃~ +60℃
Warranty	12 months

Product Images

Other LiFePO4 Battery Cells

Model No.	Nominal Voltage	Typical Capacity	Size	Charge Rate	Discharge Rate	Weight(g)	Cycle Life (80% DOD)
IFR10440	3.2V	200mAh	10.3*44.2	0.2-0.5C	0.2-3C	7	≧2000
IFR14430	3.2V	400mAh	14.2*43	0.2-0.5C	0.2-3C	13	≧2000
IFR14500	3.2V	600mAh	14.2*50.2	0.2-0.5C	0.2-3C	18	≧2000
IFR16340	3.2V	400mAh	16.2*34.2	0.2-0.5C	0.2-3C	13	≧2000
IFR18500	3.2V	1000mAh	18.1*50.2	0.2-0.5C	0.2-3C	34	≧2000
IFR18650	3.2V	1500mAh	18.5*65.3	0.2-0.5C	0.2-3C	42	≧2000
IFR18650	3.2V	1800mAh	18.5*65.3	0.2-0.5C	0.2-3C	62	≧2000
IFR22650	3.2V	1800mAh	22.5*65.3	0.2-0.5C	0.2-3C	64	≧2000
IFR26650	3.2V	3400mAh	26.5*65.3	0.2-0.5C	0.2-3C	85	≧2000
IFR26650	3.2V	3600mAh	26.5*65.3	0.2-0.5C	0.2-3C	90	≧2000
IFR26650	3.2V	3600mAh	26.5*65.3	0.2-0.5C	0.2-3C	90	≧2000
IFR32700	3.2V	6000mAh	32.5*65.3	0.2-0.5C	0.2-3C	150	≧2000

Why Choose Us

Technology

All-weather applicability (-30~60℃)
Highly safe battery design technology with the newest electrolyte and separator technology applied
Full Coverage of Battery Variety: Lithium ion Cylindrical battery, lithium polymer battery, LiFePO4 battery, Solar Energy Storage battery pack, square aluminum shell, Primary Battery, etc.

R & D

Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.

Quality Control

Certifications

CE RoHs BIS KC CB UL MSDS UN38.3 IEC61233

Factory Tour

Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery pack since 2001.
