703450 3.7v Rechargeable Li Ion Polymer Battery With Pcm

Product Description:

Li Polymer Battery is an advanced type of rechargeable battery, which contains a lithium-based chemistries in a polymer electrolyte. It offers superior performance over other lithium-ion batteries, with an overdischarge protection voltage of 2.75V, charging voltage of up to 4.2V, a charging current of 1C, and a wide discharging temperature range of -20 to 60℃. Li Polymer Battery is a reliable source of power for a variety of applications, and is known for its lightweight, flexible design. This makes them ideal for use in portable devices, such as smartphones, tablets, and laptops. Li Polymer Battery Packs are also available, allowing for larger capacity and enhanced performance. By choosing a Li Poly Battery Source, you can rest assured that you're getting the very best in lithium-polymer technology.



Features:

• Li Poly Battery: Short Circuit Protection: Yes, Capacity: 3000mAh, Overcharge Protection Voltage: 4.25V, Charging Temperature: 0-45℃, Charging Voltage: 4.2V
• Lithium Poly Battery Pack: Short Circuit Protection: Yes, Capacity: 3000mAh, Overcharge Protection Voltage: 4.25V, Charging Temperature: 0-45℃, Charging Voltage: 4.2V
• Lithium Polymer Power Source: Short Circuit Protection: Yes, Capacity: 3000mAh, Overcharge Protection Voltage: 4.25V, Charging Temperature: 0-45℃, Charging Voltage: 4.2V





Technical Parameters:

Property	Value
Short Circuit Protection	Yes
Discharging Temperature	-20-60℃
Discharging Current	2C
Overcharge Protection Function	Yes
Type	Li Polymer Battery
Overcharge Protection Voltage	4.25V
Charging Voltage	4.2V
Capacity	1300mAh
Charging Current	1C
Voltage	3.7V



Product Description

Item	Specification
Product Name	703450 3.7v rechargeable battery with PCM for Electric piano
Battery model	703450
Nominal voltage	3.7V
Minimum capacity	1300mAH (0.2C discharge)
Charging cut-off voltage	4.2V
Discharging cut-off voltage	2.75V-3.0V
Standard charging	0.2C /4.2V
Max charging	1.0C /4.2V
Standard discharging	0.2C/2.75V-3.0V
Max discharging	1.0C/2.75V-3.0V
Shipment voltage	≥3.85V
Battery pack impedance	≤80mΩ
Operating temperature	Charging: 0°C ~ 45°C
	Discharging: -20°C ~60°C
Storage (At 50% SOC and specified temp, recoverable capacity in % vs time )	-10℃~25℃ (12 months ≥85% ) -10℃ ~45℃ (6 months ≥85% ) -10℃~55℃ (1 month ≥90% ) 20±5℃ is the recommended storage temperature
Visual Inspection	There should not be any remarkable scratches, cracks,bolts, cauterization, deformations, swelling, leakage and so on the surface of the cell.
Reference standard	GB/T 18287-2013,KC,CE,ROHS,IEC/EN62133 UL1642,MSDS,CB,PSE

Applications:

The GPE Li Polymer Battery is an ideal solution for those in need of a reliable source of power. With a short circuit protection, discharging current of 2C and charging current of 1C, it is an ideal source of power for a variety of applications. With an overdischarge protection voltage of 2.75V, the GPE Li Polymer Battery is the perfect choice for those looking for a reliable and long-lasting power source.

• Portable Electronics: Li Polymer Batteries are perfect for powering portable electronic devices like mobile phones, tablets, laptops, and cameras.
• Industrial Equipment: Li Polymer Batteries are also great for powering industrial equipment like robots, machinery, and other industrial automation systems.
• Medical Devices: Li Polymer Batteries are also effective for powering medical devices like pacemakers, insulin pumps, and other medical equipment.
• Transportation: Li Polymer Batteries are perfect for powering electric vehicles, bicycles, and other forms of transportation.
• Consumer Electronics: Li Polymer Batteries are also great for powering consumer electronics like gaming systems, home appliances, and toys.

Customization:

Support and Services:

We provide technical support and services for Li Polymer Battery products. Our knowledgeable technical team is available to answer questions and provide technical support.

• Answer technical questions about Li Polymer Battery products
• Troubleshoot and diagnose technical issues related to Li Polymer Battery products
• Provide software updates and upgrades
• Provide technical advice and guidance
• Provide product installation and setup assistance

Packing and Shipping:

Li Polymer Battery should be securely packaged to ensure its safe delivery. This includes using appropriate protective materials, such as a padded bag, cardboard box, or bubble wrap. It is also important to label the package with necessary information, such as a return address, the receiver’s address, and a brief description of the contents.

When shipping, it is important to choose a reliable and reputable carrier. It is also important to obtain a tracking number for the package in order to ensure that it will reach its destination. Additionally, the package should be insured to cover any potential damages that may occur during transit.

FAQ:
