LiFePO4 Battery Cell

UN38.3 Certified 3.2V 105Ah LFP Prismatic Cell with 6000 Cycles Lifepo4 Battery

All Category

Solar Energy Storage Batteries

Rechargeable Lithium Batteries

Portable Power Station

Mrs. Linda

linda@szgpebattery.com

+86 15817210994

Contact Now

UN38.3 Certified 3.2V 105Ah LFP Prismatic Cell with 6000 Cycles Lifepo4 Battery

Model Number:	LFP105Ah
MOQ:	100pieces
Packaging Details:	Bulk packing
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

UN38.3, MSDS, IEC62133, UL

Nominal Voltage:

Typical Capacity:

105Ah

Dimensions:

135*200*36mm

Initial Impedance:

≤0.7mΩ

Cycle Life:

6000times

Weight:

1.9kg

Supply Ability:

10'000Pieces daily

Highlight:

UN38.3 LFP Prismatic Cell

105Ah LFP Prismatic Cell

3.2V LiFePO4 Battery Cell

Product Description

UN38.3 Golf Cart LFP Prismatic Cell 6000 Cycles 105Ah 3.2V Lifepo4

LFP Prismatic Cell Features

Lighter in weight, heavier on power than lead acid battery
Uses A-grade cells with more than 6000 cycle times
Max discharge continuous current: 1C to 3C 5C
Maintenance free with parallel and series connection capability
Safer performance with comprehensive safety testing
Optional: Lithium Battery built with BMS

Lifepo4 Prismatic Cell 3.2V 105Ah Specifications

Battery Type	LFP battery prismatic cell
Model	105 AH
Dimension	H200W130T36mm
Nominal capacity	105Ah
Nominal voltage	3.2v
AC Impedance Resistance	0.5mΩ
Discharging cut-off Voltage	1C
Pulse discharge rate (30s)	3C
Price	wholesale price
Customize	yes
Weight	1.9kg
Cycle life	more than 6000 times
Operating temperature	Discharge: -20°C--60°C Charge: 0°C--45°C

Other Hot Sale Lithium Iron Phosphate Battery Cells

Model No.	Standard Voltage	Standard Capacity (Ah)	Impendence (mΩ)	Weight (Kg)	Height (mm)	Width (mm)	Thickness (mm)
LFP50	3.2V	50Ah	≤0.7mΩ	1.4Kg	185.3±0.5	135.3±0.5	29.3±0.5
LFP80	3.2V	80Ah	≤0.5mΩ	1.68Kg	170±0.5	130.3±0.5	36.7±0.5
LFP90	3.2V	90Ah	≤0.5mΩ	2.0Kg	200.5±0.5	130.3±0.5	36.7±0.5
LFP100	3.2V	100Ah	≤0.5mΩ	1.92Kg	118±0.5	160±0.5	49.9±0.5
LFP105	3.2V	105Ah	≤0.5mΩ	1.98Kg	200.5±0.5	130±0.5	36.7±0.5
LFP173	3.2V	173Ah	≤0.5mΩ	3.25Kg	207.2±0.5	173.9±0.5	41.0±0.5
LFP230	3.2V	230Ah	≤0.25mΩ	4.11Kg	207.0±0.5	173.9±0.5	54.0±0.5
LFP280	3.2V	280Ah	≤0.25mΩ	5.42Kg	207.5±0.5	173.7±0.5	72.0±0.5
LFP304	3.2V	304Ah	≤0.5mΩ	5.49Kg	208.8±0.5	173.5±0.5	72.0±0.5

Product Images

Why Choose Us

Technology

All-weather applicability (-30~60℃)
Highly safe battery design technology with the newest electrolyte and separator technology
Full Coverage of Battery Variety: Lithium ion Cylindrical battery, lithium polymer battery, LiFePO4 battery, Solar Energy Storage battery pack, square aluminum shell, Primary Battery, etc.

R & D

Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.

Certificates

CE RoHs BIS KC CB UL MSDS UN38.3 IEC61233

Factory Tour
