| Model Number: | IFR32700 |
| MOQ: | 500pieces |
| Packaging Details: | Bulk packing |
| Payment Terms: | T/T |
| Battery Type | LiFePO4 Battery Cell |
| Rated Voltage | 3.2V |
| Rated Capacity | 6000mAh |
| Recommended Charge Current | 0.2C |
| Continuous Charge Current | 1.0C |
| Continuous Discharge Current | 1.0C |
| Max. Discharge Current | 3.0C |
| Max. Pulse Discharge Current | 5.0C |
| Discharge Cut-off Voltage | 2.0V |
| Charge Limited Voltage | 3.65V±0.03V |
| Internal Impedance | ≤10mΩ |
| Charge Temperature (CC/CV) | 0~45°C |
| Discharge Temperature (CC/CV) | -20~60°C |
| Cycle Life | ≥3000 cycles |
| Dimension | 32*70mm |
| Weight | 140g |
| Model No. | Nominal Voltage | Typical Capacity | Size | Charge Rate | Discharge Rate | Weight(g) | Cycle Life (80% DOD) |
|---|---|---|---|---|---|---|---|
| IFR10440 | 3.2V | 200mAh | 10.3*44.2 | 0.2-0.5C | 0.2-3C | 7 | ≥2000 |
| IFR14430 | 3.2V | 400mAh | 14.2*43 | 0.2-0.5C | 0.2-3C | 13 | ≥2000 |
| IFR14500 | 3.2V | 600mAh | 14.2*50.2 | 0.2-0.5C | 0.2-3C | 18 | ≥2000 |
| IFR16340 | 3.2V | 400mAh | 16.2*34.2 | 0.2-0.5C | 0.2-3C | 13 | ≥2000 |
| IFR18500 | 3.2V | 1000mAh | 18.1*50.2 | 0.2-0.5C | 0.2-3C | 34 | ≥2000 |
| IFR18650 | 3.2V | 1500mAh | 18.5*65.3 | 0.2-0.5C | 0.2-3C | 42 | ≥2000 |
| IFR18650 | 3.2V | 1800mAh | 18.5*65.3 | 0.2-0.5C | 0.2-3C | 62 | ≥2000 |
| IFR22650 | 3.2V | 1800mAh | 22.5*65.3 | 0.2-0.5C | 0.2-3C | 64 | ≥2000 |
| IFR26650 | 3.2V | 3400mAh | 26.5*65.3 | 0.2-0.5C | 0.2-3C | 85 | ≥2000 |
| IFR26650 | 3.2V | 3600mAh | 26.5*65.3 | 0.2-0.5C | 0.2-3C | 90 | ≥2000 |
| IFR26650 | 3.2V | 4000mAh | 26.5*65.3 | 0.2-0.5C | 0.2-3C | 90 | ≥2000 |
| IFR32700 | 3.2V | 6000mAh | 32.5*65.3 | 0.2-0.5C | 0.2-3C | 150 | ≥2000 |
