| Model Number: | LFP12V150 |
| MOQ: | 10pieces |
| Packaging Details: | Carton box or wooden box |
| Payment Terms: | T/T |
| Item | Specification | Note |
|---|---|---|
| Nominal Voltage | 12.8V | Any voltage can be customized |
| Nominal Capacity | 150Ah | Any capacity can be customized |
| Discharge Cut-Off | 10V | |
| Charge Cut-Off | 14.6V | |
| Charge Current | 0.2-0.5C | Free customization service |
| Continuous Discharge | 100A | Free customization service |
| Peak Discharge | 200A | Free customization service |
| Impedance | ≤200mΩ | |
| Charge Temperature | 0℃ - 45℃ | |
| Discharge Temperature | -20℃ - 60℃ | |
| Charge Method | CC/CV | |
| Life Cycle | 2000+ | 80% DOD, Max. 95% DOD |
| BMS | With BMS | |
| Dimension | 330*175*220mm | Any dimension can be customized |
| Weight | 22KG |
| Voltage | Typical Capacity | Charge | Discharge | Dimension(mm) | Weight(Kg) |
|---|---|---|---|---|---|
| 12V | 10AH | 0.2C-2C | 0.2C-2C | 150*92*65 | 1.6 |
| 12V | 50AH | 0.2C-2C | 0.2C-2C | 195*165*175 | 9.5 |
| 12V | 100AH | 0.2C-2C | 0.2C-2C | 330*175*220 | 19 |
| 12V | 200AH | 0.2C-2C | 0.2C-2C | 525*240*215 | 30 |
| 24V | 10AH | 0.2C-2C | 0.2C-2C | 181*77*175 | 4.5 |
| 24V | 50AH | 0.2C-2C | 0.2C-2C | 330*175*220 | 18 |
| 48V | 50AH | 0.2C-2C | 0.2C-2C | 522*237*215 | 33 |
| 48V | 75AH | 0.2C-2C | 0.2C-2C | 522*237*215 | 42 |
| 48V | 100AH | 0.2C-2C | 0.2C-2C | 350*540*160 | 52 |
Experienced R&D team with over 60 engineers and advanced equipment for supporting OEM and ODM requirements.
CE, RoHs, BIS, KC, CB, UL, MSDS, UN38.3, IEC61233 certificated.
Shenzhen Gold Power Energy Co., Ltd is one of the leading battery suppliers in China. We have started to offer various batteries including Li polymer battery, Lithium ion battery, LiFePO4 battery, and customized battery pack since 2001.
